Install the Switch with Shelf Brackets
Shelf Kit Contents
The shelf kit is not part of the standard accessory kit. You must order it separately by using the chassis-specific
part number.
Note
Shelf Kit Part NumberSwitch Model
C9404-SHELF-KIT=Catalyst 9404R Switch
C9407-SHELF-KIT=Catalyst 9407R Switch
C9410-SHELF-KIT=Catalyst 9410R Switch
The following table lists the contents of the shelf kit:
Table 6: Shelf Kit Contents
Quantity
(C9410-SHELF-KIT=)
Quantity
(C9407-SHELF-KIT=)
Quantity
(C9404-SHELF-KIT=)
Item and Description
111Left L bracket.
Fabricated metal chassis L bracket, to secure the chassis
to the rack enclosure.
111Right L bracket.
Fabricated metal chassis L bracket, to secure the chassis
to the rack enclosure
222Shelf brackets
Fabricated metal, rack shelf brackets, to support the
weight of the chassis.
66612-24 x 0.75-inch Phillips screws
66610-32 x 0.75-inch Phillips screws
1084M4 x 8 mm Phillips flat head screws
111Documentation, pointer card
Provides references to related documentation on
cisco.com
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
53
Installing the Switch
Install the Switch with Shelf Brackets
