Cisco Catalyst 9400 Series User Manual

CHAPTER 5
Installing the Switch
• Installation Tasks , on page 47
• Unpacking the Switch, on page 49
• Install the Switch as Shipped, on page 50
• Install the Switch with Shelf Brackets, on page 53
• Installing the Cable Guide, on page 65
• Install the Switch in a NEBS-Compliant Mode, on page 70
• Establishing System Ground, on page 79
• Attaching an ESD Strap, on page 81
• Verifying the Switch Chassis Installation, on page 84
Installation Tasks
These warnings apply to the overall switch installation process:
IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with
standard practices for preventing accidents. Use the statement number provided at the end of each
warning to locate its translation in the translatedsafety warnings that accompanied thisdevice.Statement
1071
SAVE THESE INSTRUCTIONS
Warning
Class 1 laser product. Statement 1008
Warning
This unit is intended for installation in restricted access areas. A restricted access area can be accessed only
through the use of a special tool, lock and key, or other means of security. Statement 1017
Warning
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
47

Cisco Catalyst 9400 Series Specifications

General

Series	Catalyst 9400 Series
Form Factor	Rack-mountable
Operating System	Cisco IOS XE
Uplink Options	40G and 100G uplinks
Stacking	Not supported
Layer Support	Layer 2 and Layer 3
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 90% noncondensing
Power Supply Options	AC and DC power supplies
Redundancy	Power supply, supervisor engine
Modular Slots	7 or 10
MAC Address Table Size	256, 000
Security Features	ACLs, TrustSec, MACsec
Management	CLI, SNMP, NETCONF, RESTCONF, Cisco DNA Center
