Removing and Installing a Fan Tray
Online Insertion and Removal
While the fan tray is designed to be removed and installed while the system is operating (powered on) and
without presenting an electrical hazard or damage to the system, there is a time constraint when you remove
and replace the fan tray in a system that is powered on.
If the service mode is not enabled, the system can safely run without a fan tray only for two minutes, until
critical temperature threshold is exceeded. Watch for any alarms triggered in software. After the critical
temperature threshold is exceeded, without sufficient cooling, the system shuts down if the alarm is not cleared.
Caution
When the fan tray is removed and replaced in a non operating system, there is no time constraint.
Following the Correct Removal and Replacement Procedure
When you order the fan tray or a spare, the entire fan tray assembly is shipped. The fan tray assembly consists
of the fan tray and an adapter that is attached to the fan tray.
You can remove and replace the fan tray from the front or the rear. When removed from the front of the
chassis, only the fan tray is removed. When removed from the rear, the entire fan tray assembly (including
the adapter) is removed. Accordingly, you must detach the adapter from the spare fan tray assembly when
installing or replacing the fan tray from the front; you must install the entire fan tray assembly when installing
the spare from the rear.
Removal and replacement from the front is suited to situations where access to the rear of the system is
restricted. For instance, where the installation is in a closet.
Removal and replacement from the rear is suited to situations where input and output cables are routed across
the front panel, limiting access to the front panel of the fan tray.
Follow the corresponding removal and replacement procedures.
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
85

Cisco Catalyst 9400 Series Specifications

General

Series	Catalyst 9400 Series
Form Factor	Rack-mountable
Operating System	Cisco IOS XE
Uplink Options	40G and 100G uplinks
Stacking	Not supported
Layer Support	Layer 2 and Layer 3
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 90% noncondensing
Power Supply Options	AC and DC power supplies
Redundancy	Power supply, supervisor engine
Modular Slots	7 or 10
MAC Address Table Size	256, 000
Security Features	ACLs, TrustSec, MACsec
Management	CLI, SNMP, NETCONF, RESTCONF, Cisco DNA Center
