Cisco Catalyst 9400 Series User Manual

DescriptionFeature
Supports 1+1 supervisor module redundancy for integrated resiliency. Supported model numbers (add = for
spare):
• Cisco Catalyst 9400 Series Supervisor 1 Module (C9400-SUP-1)
• Cisco Catalyst 9400 Series Supervisor 1XL Module (C9400-SUP-1XL)
• Cisco Catalyst 9400 Series Supervisor 1XL-Y 25G Module (C9400-SUP-1XL-Y)
Supervisor modules:
• Must be installed in slots numbered 5 and 6 only.
• Have minimum software release version requirements. Refer to your software release notes for this
information.
See Cisco Catalyst 9400 Series Supervisor Module Installation Note
Supervisor
modules
Accomodates five line cards. Supported model numbers (add = for spare):
• Cisco Catalyst 9400 Series 48-Port UPOE 10/100/1000 Module (C9400-LC-48U)
• Cisco Catalyst 9400 Series 48-Port 10/100/1000 Module (C9400-LC-48T)
• Cisco Catalyst 9400 Series 24-Port SFP/SFP+ Module (C9400-LC-24XS)
• Cisco Catalyst 9400 Series 48-Port UPOE Multigigabit Module (C9400-LC-48UX)
• Cisco Catalyst 9400 Series 48-Port SFP Module (C9400-LC-48S)
• Cisco Catalyst 9400 Series 24-Port SFP Module (C9400-LC-24S)
• Cisco Catalyst 9400 Series 48-Port Gigabit Ethernet POE/POE+ Module (C9400-LC-48P)
• Cisco Catalyst 9400 Series 48-Port Gigabit Ethernet UPOE+ 10/100/1000 Module (C9400-LC-48H)
See Cisco Catalyst 9400 Series Switching Module Installation Note
Switching
modules
The switch supports a single front and rear serviceable and hot-swappable fan tray with 16 fans.
Supported model number (add = for spare)—C9410-FAN
See Fan Tray Assembly Overview, on page 16 and Fan Tray LEDs, on page 161
Fan tray assembly
The chassis supports up to four field-replaceable AC-input and DC-input power supply modules. Supported
model numbers (add = for spare):
• C9400-PWR-2100AC
• C9400-PWR-3200AC
• C9400-PWR-3200DC
See Power Supply Module Overview, on page 19 and Power Supply LEDs, on page 162
Power supplies
80 Gbps backplane bandwidth for each payload module slot.Backplane
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
15
Product Overview
Catalyst 9410R Switch

Cisco Catalyst 9400 Series Specifications

General

Series	Catalyst 9400 Series
Form Factor	Rack-mountable
Operating System	Cisco IOS XE
Uplink Options	40G and 100G uplinks
Stacking	Not supported
Layer Support	Layer 2 and Layer 3
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 90% noncondensing
Power Supply Options	AC and DC power supplies
Redundancy	Power supply, supervisor engine
Modular Slots	7 or 10
MAC Address Table Size	256, 000
Security Features	ACLs, TrustSec, MACsec
Management	CLI, SNMP, NETCONF, RESTCONF, Cisco DNA Center
