Cisco Catalyst 9500

monitors the transmit counters at the ASIC level to verify that the ports are not stuck. It also displays syslog
messages, and users can take corrective actions using the Cisco IOS Embedded Event Manager (EEM).
Configure the time interval and threshold by entering the diagnostic monitor interval and diagnostic monitor
threshold commands, respectively. The test leverages the Cisco Discovery Protocol that transmits packets.
The test runs every 75 seconds, and the failure threshold is set to 5 seconds by default.
DescriptionAttribute
Nondisruptive.Disruptive or Nondisruptive
Do not disable.Recommendation
On.Default
Cisco IOS XE Everest 16.9.1.Intitial release
Displays a syslog message indicating that a port has
failed.
Corrective action
All modules, including supervisor engines.Hardware support
Cisco Catalyst 9500 Series High Performance Switches
TestGoldPktLoopback
This GOLD packet loopback test verifies the MAC-level loopback functionality. In this test, a GOLD packet
is sent, for which Unified Access Data Plane (UADP) ASIC provides support in the hardware. The packet
loops back at the MAC-level and is matched against the stored packet.
DescriptionAttribute
Nondisruptive.Disruptive or Nondisruptive
Run this on-demand test as per requirement.Recommendation
Off.Default
Cisco IOS XE Fuji 16.8.1.Intitial release
Displays a syslog message if the test fails for a port.Corrective action
All modules.Hardware support
TestOBFL
This test verifies the on-board failure-logging capabilities. During this test, a diagnostic message is logged to
the Onboard Failure Logging (OBFL).
DescriptionAttribute
Nondisruptive.Disruptive or Nondisruptive
Run this on-demand test as per requirement.Recommendation
Off.Default
