B-7
Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Appendix B Connector Pin Assignments
Cable Pin Assignments
Figure B-6 Pin Assignments and Wiring for an RJ-45 Crossover Cable
211779
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
Brown
White/Brown
White/Blue
White/Green
White/Orange
Orange
Blue
Green
