Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Chapter 1 Overview of the Content Delivery Engines
Hardware Features
CDE205 Hardware Overview
The CDE205 ships with the following components installed:
• 1 motherboard with 2 Gigabit Ethernet ports
• 1 Quad Core Intel Xeon (Harpertown L5410) CPU @ 2.33 GHz
• 4 x 2-GB RAM modules (8 GB total)
• 1 hot-swappable power supply
• 1 x 8-GB CF + IDE interposer
• 1 SAS disk controller inserted into slot 1
• 3 x 500-GB SATA drives mounted to bay expanders designed to slide into the front of the chassis
• 9 empty bay expanders (not labeled)
Note Bay expanders with mounted disks have stickers labeling the drive numbers from 0 to 2.
CDE280-K9, SB-CDE280-2H26 CDE280 IS 2H26
CDE280-K9, SB-CDE280-2U1 CDE280 TV 2U1
CDE280-K9, SB-CDE280-2U2 CDE280 TV 2U2
CDE280-K9, SB-CDE280-2U3 CDE280 TV 2U3
CDE280-K9, SB-CDE280-2V0 CDE280 VQE 2V0
CDE280-K9, SB-CDE280-2U4 CDE280 TV 2U4
CDE285-S, SB-CDE285-2S10 CDE285-S OMD 2S10
CDE285-S, SB-CDE285-2H26 CDE285-S OMD 2H26
CDE285-S, SB-CDE285-2H40 CDE285-S OMD 2H40
CDE285-L, SB-CDE285-2H90 CDE285-L OMD 2H90
CDE420-K9, CB-32-24A1T-2QTX CDE420 TV 4A-C
CDE420-K9, CB-32-24A1T-2QSX CDE420 TV 4A-F
CDE420-K9, CB-32-24S450-3QTX CDE420 TV 4G-C
CDE420-K9, CB-32-24S450-3QSX CDE420 TV 4G-F
CDE460-K9, CB-128-HVY-2WPL-SB-36S3T CDE460 TV 4R1
CDE460-K9, CB-128-HVY-2WPL-SB-36S3T CDE460 TV 4R3
CDE475-K9,CB-128GB-4X10GE-SB-368T CDE475 TV 4A1
Table 1-3 CDE Configurations (continued)
Product Name and Part Identifier Base PID VDS Application Storage Bundle
CDE205-2-500TX-K9 CDE205 IS —
CDE220-K9, CB-32-12A1T-2QTX CDE220 TV 2A-C
CDE220-K9, CB-32-12A1T-4DSX CDE220 TV 2A-F
CDE220-K9, CB-16-4S73-1QTX CDE220 TV 2C1-C
CDE220-K9, CB-16-4S73-2DSX CDE220 TV 2C1-F
