CHAPTER 3
Hardware Components
• Hardware Components, on page 7
Hardware Components
The CE1200 is based on a UCS C220 M5L server, with the following components:
Table 3: Components and UCS equivalent part numbers for the CE1200 Appliance
QuantityPartItem
1UCS-C220-M5LChassis
1UCS-CPU-6134 (3.2 GHz
6134/130W 8C/24.75MB
Cache/DDR4 2666MHz)
Processor
2UCS-MR-X16G1RS-H (16GB)
DDR4-2666-MHz
RDIMM/PC4-21300/single
rank/x4/1.2v
RAM
2UCS-HD2T7KL12N 2 TB 12G
SAS 7.2K RPM LFF HDD
Hard Disk
1UCSC-MRAID1GB-KIT SAS
RAID KIT for C220M5l
RAID Controller
1UCSC-PCIE-ID10GF Intel
X710-DA2 dual-port 10G SFP+
NIC
NIC
2EXP-10GSFP-SR-MP (10Gb SR
Fiber SFP)
2EXP-1GSFP-T (1Gb Copper SFP
2UCSC-PSU1-770WPSU
Cisco Expressway CE1200 Appliance Installation Guide (14.0)
7
