Cisco Expressway CE1200 User Manual

LAN3 → Expressway Dedicated Management Interface (DMI) port on LAN3. It is located
on the back of the server.
Currently, with Expressway release X12.7 and later, support is available for a
Dedicated Management Interface (DMI) which uses LAN3 as an out-of-band
management interface.
Note
3a
VGA video connector4
Cisco Integrated Management Controller (CIMC) Port (1 Gb Ethernet)5
Serial port (RJ-45 connector)6
Rear identification button/LED7
Power supplies PSU 01 and PSU 02.
The second power supply can be added for 1+1 redundancy.
8
Slot 2: Low-profile PCIe slot on riser (not populated)9
Slot 1: Standard-profile PCIe slot on riser; houses two SFP ports
Left port is LAN1 (NIC1) in the Expressway user interface.
Right port is LAN2 (NIC2) if used in the interface.
10
For more information on the method to configure a Dedicated Management Interface (DMI), see Cisco
Expressway Administrator Guide.
Cisco Expressway CE1200 Appliance Installation Guide (14.0)
14
Rear Panel Layout
Rear Panel Layout
