Figure 23: CAB-L620P-C13-JPN (Japan)
Cord
set
rating:
15A,
250V
2
Plug:
NEMA
L6-20P
1
Connector:
IEC
60320-C13
3
Figure 24: CAB-9K10A-SA (South Africa)
Cord
set
rating:
10A,
250V
2
Plug:
SABS
164
1
Connector:
IEC
60320-C15
3
Cisco Firepower 4100 Series Hardware Installation Guide
30
Overview
Power Cord Specifications
33
35
