Cisco Firepower 4100 Series Hardware Installation Guide

Install the FIPS Opacity Shield
This procedure should be performed only by the Crypto Officer.Caution
Because the FIPS opacity shield covers the serial number on the chassis, you need to copy the serial
number on a label and attach it to the chassis where it can be retrieved or viewed easily before you install
the FIPS opacity shield. You need the serial number when you call Cisco TAC.
Note
Before You Begin
You need the following to install the FIPS opacity shield:
•
#1 Phillips head screwdriver
•
The following items from the FIPS kit:
◦
One FIPS opacity shield
◦
Four 8-32 x .375" countersink screws used to secure the FIPS opacity shield to the cable management
brackets
◦
15 tamper-evident labels (TELs)
•
The following items from the Firepower 4100 accessory kit:
◦
Two cable management brackets
◦
Four 8-32 x .375" countersink screws used to secure the cable management brackets to the slide
rail locking brackets
Step 1
Copy the serial number on a label and attach it to the chassis where it can be retrieved easily for future use if needed.
To find the serial number, see Serial Number Location, on page 5.
Step 2
Pull the chassis out of the rack until the release latches catch.
Step 3
If you have not already done so, attach a slide rail locking bracket to each side of the chassis using the six 8-32 x .375"
countersink Phillips head screws provided in the accessory kit.
Cisco Firepower 4100 Series Hardware Installation Guide
50
Mount and Connect
Install the FIPS Opacity Shield
