You should have completed this step while preforming the procedure described in Rack-Mount the Chassis,
on page 43.
Note
Figure 36: Attach the Slide Rail Locking Bracket to the Side of the Chassis
Slide rail locking bracket2Chassis1
8-32 x .375" countersink Phillips head screws
(3 per side)
3
Cisco Firepower 4100 Series Hardware Installation Guide
51
Mount and Connect
Install the FIPS Opacity Shield
