Cisco Firepower 4100 Series Hardware Installation Guide

c) Slide the release clip toward the rear on both inner rails, and then continue pushing the chassis into the rack until the
mounting brackets meet the front of the slide rail.
Figure 35: Inner Rail Release Clip
Inner rail attached to chassis2Inner rail release clip1
Outer rail attached to rack post3
Step 6
Use the captive screws on the front of the mounting brackets to fully secure the chassis to the rack.
What to Do Next
Continue with Connect Cables, Turn on Power, and Verify Connectivity, on page 55.
Cisco Firepower 4100 Series Hardware Installation Guide
48
Mount and Connect
Rack-Mount the Chassis
