Cisco IE 3000 Switch Hardware Installation Guide
Appendix B Installation In a Hazardous Environment
Adding Modules to the Switch
Note The expansion modules cannot operate as standalone devices; a switch is required for the expansion
module to operate.
Expansion Module Configurations
Both the IE-3000-4TC and the IE-3000-8TC switches can be configured with one or two expansion
modules to increase the number and types of ports for the switch. Table B-1 lists the supported port
combinations of switch and expansion modules. The table also provides a breakdown of the type and
quantity of ports for a particular switch expansion module combination.
Table B-1 Cisco IE-3000-4TC and Cisco IE-3000-8TC Switch Expansion Module Configurations
and Port Types
Expansion Module Configurations Port Types and Quantity (Including Switch Ports)
Expansion Module 1 Expansion Module 2 IE-3000-4TC Switch IE-3000-8TC Switch
— — 10/100FE—4 10/100FE—8
Cisco IEM-3000-4PC — 10/100FE—4
10/100BASE-T—4
10/100FE—8
10/100BASE-T—4
Cisco IEM-3000-4PC Cisco IEM-3000-4PC 10/100FE—4
10/100BASE-T—8
10/100FE—8
10/100BASE-T—8
Cisco IEM-3000-4PC Cisco IEM-3000-4PC-4TC 10/100FE—4
10/100BASE-T—12
10/100FE—8
10/100BASE-T
2
—12
Cisco IEM-3000-4PC Cisco IEM-3000-4SM 10/100FE—4
100BASE-X—4
10/100BASE-T—4
10/100FE—8
100BASE-X—4
10/100BASE-T—4
Cisco IEM-3000-4PC Cisco IEM-3000-8FM 10/100FE—4
100FX—8
10/100BASE-T—4
10/100FE—8
100FX—8
10/100BASE-T—4
Cisco IEM-3000-4PC Cisco IEM-3000-8SM 10/100FE—4
100BASE-X—8
10/100BASE-T—4
10/100FE—8
100BASE-X—8
10/100BASE-T—4
Cisco IEM-3000-4PC Cisco IEM-3000-8TM 10/100FE—12
10/100BASE-T—4
10/100FE—16
10/100BASE-T—4
Cisco IEM-3000-4PC-4TC — 10/100FE—4
10/100BASE-T—8
10/100FE—8
10/100BASE-T—8
Cisco IEM-3000-4PC-4TC Cisco IEM-3000-4PC 10/100FE—4
10/100BASE-T—12
10/100FE—8
10/100BASE-T—12
Cisco IEM-3000-4PC-4TC Cisco IEM-3000-4PC-4TC 10/100FE—4
10/100BASE-T—16
10/100FE—8
10/100BASE-T—16
Cisco IEM-3000-4PC-4TC Cisco IEM-3000-4SM 10/100FE—4
100BASE-X—4
10/100BASE-T—4
10/100FE—8
100BASE-X—4
10/100BASE-T—4
