Rack Mount Kit includes:
▪ US 12-24 mounting screws and cage nuts, 5 of each
▪ INTL M5 mounting screws and cage nuts, 5 of each
▪ INTL M6 mounting screws and cage nuts, 5 of each
▪ Mounting washers
MS220-24 Series front panel
MS220-48 Series front panel
Ports and Status Indicators
The MS uses LEDs to inform the user of the device's status. When the device powers on, all the Internet LEDs flash
twice. Additional functions are described below, from left to right.
Item Function LED Status Meaning
