32
D1507602 User Guide
Cisco TelePresence MX200 G2, MX300 G2
SX80
Produced: April 2014 for TC 7.1
All contents © 2010–2014
Cisco Systems, Inc. All rights reserved.
Share content
Change Presentation Layout
You may change the layout of the
screen during presentations. Typical
options available will be with or
without showing the presenter and
showing the presenter as either
a PiP (Picture in Picture) or PoP
(Picture outside Picture).
The layout options available on
your system may dier from those
shown here, but the layouts shown
are always those you may choose
between.
About Presentation Layout
Tap Layout, as outlined, to invoke the layout options.
Select your preferred layout
by tapping it.
