Camera
View Camera Settings
Tap Camera, as outlined, to
invoke the camera adjustment
menu.
Turn Selfview
On and O.
Maximize/minimize Selfview.
Select which camera to
control (for congurations
with more than one camera).
Zoom in and out.
Pan and tilt controls.
Any camera presets
dened will be listed
here.
About Camera Settings
The camera settings let you control
the zoom, pan and tilt of the camera
as well as dene and edit camera
position presets.
In addition selfview (the image that
the others see from your system)
can be turned on and o as well as
be shown minimized or maximized.
If the position of the selfview blocks
important parts of the image on your
screen, it can be moved. How to do
this is shown in “Move the Selfview
PiP” on page 49.
Pan
Tilt
Zoom

Cisco MX200 G2 Specifications

General

Control	Touch 10 control unit
Video Standards	H.264, H.265
Frame Rate	Up to 60 fps
Ethernet Ports	1 x RJ-45
OS	Cisco Collaboration Endpoint Software
Microphone	Integrated microphone array
Network	Gigabit Ethernet
Video Inputs	HDMI
Video Outputs	HDMI
Audio Standards	G.711, G.722, AAC
Network Protocols	TCP/IP, DHCP, DNS
Audio Inputs	3.5 mm mini jack
Audio Outputs	3.5mm jack
Audio Codecs	AAC-LD, Opus
Mounting	Wall mount
Compatibility	Cisco Webex, SIP
