Cisco NCS 1001 Hardware Installation Guide

Figure 38: Insert Power Supply
Insert the PSU into the cage on the rear side of the unit in the direction shown (slots 0 or 1)1
The PSU connecting PCB must always face the bottom during insertion2
Direction to insert the power supply3
Remove Power Supply
The inlet temperature of system during replacement must be less than 40 deg Celsius at sea level. The
replacement time decreases for higher altitudes.
Note
In case of PSU failure, the failed PSU needs to be physically replaced within 2 minutes.
Note
Figure 39: Hot Area on PSU Faceplate
Hardware Installation Guide for Cisco NCS 1001
42
Replace Cisco NCS 1001 Components
Remove Power Supply
