Configuring a Gateway-to-Gateway VPN Tunnel Between RV0xx Series Routers

Configuring a VPN Tunnel on a Cisco RV0xx Series Router

Cisco Small Business RV0xx Series Routers Administration Guide 179

Example: Site with a Dynamic WAN IP Address

Settings on the Site A Router:

Phase 1

Authentication

MD5

Phase 1 SA Life

Time

28800

Perfect Forward

Secrecy

Enabled

Phase 2 DH

Group

Group 1 - 768 bit

Phase 2

Encryption

DES

Phase 2

Authentication

MD5

Phase 2 SA Life

Time

3600

Preshared Key 13572468#123456789

Minimum

Preshared Key

Complexity

Enabled

Advanced Default settings

Field Value

Local Group Setup

Local Security

Gateway Type

IP Only

IP Address (Automatically detected) 203.165.200.226

Field Values
