Configuring IPSec with a Windows 2000 or XP Computer
4-Port Gigabit Security Router with VPN
Appendix C
Filters Properties
If you want to enter a description for your filter, click 10.
the Description tab and enter the description there.
Click 11. OK or Close and the New Rule Properties screen
appears with the IP Filter List tab selected. The screen
will contain listings for Router->win and win->Router.
Click OK (Windows XP) or Close (Windows 2000) in the
IP Filter List window.
New Rule Properties
Step 3: Configure Individual Tunnel Rules
Tunnel 1: win->Router
On the 1. IP Filter List tab, select filter list win->Router.
IP Filter List Tab
Click the 2. Filter Action tab, and click the filter action
Require Security radio button. Then, click Edit.
Filter Action Tab
On the 3. Security Methods tab, verify that the Negotiate
security option is enabled, and deselect the Accept
unsecured communication, but always respond
using IPSec check box. Select Session key Perfect
Forward Secrecy, and click OK.
Security Methods Tab
Select the 4. Authentication Methods tab, and click
Edit.
Authentication Methods Tab
Change the authentication method to 5. Use this string to
protect the key exchange (preshared key), and enter
the preshared key string, such as XYZ12345. Click OK.
To Next Page
