Port Management
Configuring LAG Settings
Cisco Small Business 300 Series Managed Switch Administration Guide 93
9
Defining Member Ports in a LAG
The LAG Management Page enables you to define the member ports in a LAG.
STEP 1 Select the LAG to be configured, and click Edit. The
Edit LAG Membership Page
opens.
STEP 2 Enter the values for the following fields:
• LAG—Select the LAG number.
• LAG Name—Enter the LAG name or a comment.
• LACP—Select to enable LACP on the selected LAG. This makes it a dynamic
LAG.
• Port List—Move those ports that are to be assigned to the LAG from the
Port List to the LAG Members list. Up to eight ports per static LAG can be
assigned, and 16 ports can be assigned to a dynamic LAG.
STEP 3 Click Apply. The LAG membership is defined, and the switch is updated.
You can select another LAG for configuration by changing the LAG field.
Configuring LAG Settings
The
LAG Settings Page
displays a table of current settings for all LAGs. You can
configure the settings of selected LAGs, and reactivate suspended LAGs by
launching the Edit LAG Settings Page.
To configure the LAG:
STEP 1 Click Port Management > LAG Aggregation > LAG Settings. The
LAG Settings
Page
opens.
STEP 2 Select a LAG, and click Edit. The
Edit LAG Settings Page
opens.
STEP 3 Enter the values for the following fields:
• LAG—Select the LAG ID number.
• Description—Enter the LAG name or a comment.
• LAG Type—Displays the port type that comprises the LAG.
