Disassociating a Fabric Extender From an Interface
Before You Begin
Ensure that you have installed and enabled the Fabric Extender feature set.
Ensure that you are in the correct VDC (or use the switchto vdc command).
SUMMARY STEPS
1.
configure terminal
2.
interface {ethernet slot/port | port-channel channel}
3.
no fex associate
DETAILED STEPS
PurposeCommand or Action
Enters configuration mode.configure terminal
Example:
switch# configure terminal
switch(config)#
Step 1
Specifies the interface to configure. The interface can
be an Ethernet interface or a port channel.
interface {ethernet slot/port | port-channel channel}
Example:
switch(config)# interface port-channel 4
switch(config-if)#
Step 2
Disassociates the Fabric Extender unit attached to the
interface.
no fex associate
Example:
switch(config-if)# no fex associate
Step 3
Associating a Fabric Extender to an F2 Module
You can associate the Fabric Extender to an F2 module.
Before You Begin
Ensure that you have installed and enabled the Fabric Extender feature set.
• switch# configure terminal
• switch(config)# install feature-set fex
• switch(config)# feature-set fex
Cisco Nexus 2000 Series NX-OS Fabric Extender Software Configuration Guide
OL-25816-02 19
Configuring the Fabric Extender
Associating a Fabric Extender to a Fabric Interface

Cisco SGE2000 Specifications

General

Jumbo Frame Support	9KB
VLANs	Up to 256
Management	Web-based, SNMP, CLI
Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1D, 802.1Q, 802.1p, 802.1w
Dimensions	440 x 44 x 257 mm
Power Supply	100 to 240V AC, 50-60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 90% non-condensing
Weight	3.2 kg
