PurposeCommand or Action
Specifies the module type.limit-resource module-type f2
Example:
switch(config)# limit-resource module-type f2
Step 2
Specifies the interface.interface ethernet <mod-number><port-range>
Example:
switch(config)# interface ethernet 1/1
Step 3
Allocates the F2 interfaces to VDC.allocate interface ethernet <slot-port>
Example:
switch(config)# allocate interface ethernet 1
Step 4
Specifies the FEXswitchport mode fex -fabric
Example:
switch(config-if)# switchport mode fex -fabric
Step 5
Specifies the chassis.fex associate <FEX chassis number>
Example:
switch(config-if)# fex associate 101
Step 6
Specifies the port channel number.channel-group <port-channel number>
Example:
switch(config-if)# channel-group 1
Step 7
Brings up port.no shutdown
Example:
switch(config-if)# no shutdown
Step 8
Specifies the port channel.int po <port-channel number>
Example:
switch(config-if)# int po 1
Step 9
Brings up the port channel.no shutdown
Example:
switch(config-if)# no shutdown
Step 10
Configuring Fabric Extender Global Features
You can configure global features on the Fabric Extender.
Cisco Nexus 2000 Series NX-OS Fabric Extender Software Configuration Guide
OL-25816-02 21
Configuring the Fabric Extender
Configuring Fabric Extender Global Features

Cisco SGE2000 Specifications

General

Jumbo Frame Support	9KB
VLANs	Up to 256
Management	Web-based, SNMP, CLI
Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1D, 802.1Q, 802.1p, 802.1w
Dimensions	440 x 44 x 257 mm
Power Supply	100 to 240V AC, 50-60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 90% non-condensing
Weight	3.2 kg
