Support for UEFI Secure Boot
The SNS 3515 and SNS 3595 appliances support the Unified Extensible Firmware Interface (UEFI) secure
boot feature. This feature ensures that only a Cisco-signed ISE image can be installed on the SNS 3515 and
SNS 3595 appliances, and prevents installation of any unsigned operating system even with physical access
to the device. For example, generic operating systems, such as Red Hat Enterprise Linux or Microsoft Windows
cannot boot on this appliance.
LED Indicators on Cisco SNS 3515 and 3595 Appliances
This section describes the front- and rear-panel controls, ports, and LED indicators on the Cisco SNS 3515
and Cisco SNS 3595 appliances.
Cisco SNS-3515 and SNS-3595 Appliances Hardware Specifications
The following table describes the hardware specifications of Cisco SNS-3515 and Cisco SNS-3595 appliances.
DiagramsHardware SpecificationsCisco Identity Services
Engine Appliance
Cisco SNS-3515 or 3595 Appliance
Front Panel View, on page 3
Cisco SNS 3515 or SNS 3595
Appliance Back Panel View, on
page 5
• Cisco UCS C220 M4
• Single socket Intel Xeon E5-2620
v3 series CPU @ 2.40GHz, 12 total
cores, 6*2 total threads
• 16 GB RAM
• 1 x 600-GB disk
• 6 GbE network interfaces
• For physical, environmental, and
power specifications, see Server
Specifications, on page 12
Cisco SNS-3515-K9
• Cisco UCS C220 M4
• Dual socket Intel Xeon E5-2640 v3
series CPU @ 2.60GHz, 16 total
cores, 8*2 total threads
64 GB RAM
4 x 600-GB disks
RAID 10
6 GbE network interfaces
For physical, environmental, and
power specifications, see Server
Specifications, on page 12.
Cisco SNS-3595-K9
Install Cisco ISE Software on Cisco SNS Appliances
2
Install Cisco ISE Software on Cisco SNS Appliances
LED Indicators on Cisco SNS 3515 and 3595 Appliances
