Cisco TelePresence MX200 G2 User Manual

8
D1534504 User Guide
Cisco TelePresence
Produced: November 2016 for CE 8.2
All contents © 2010–2016
Cisco Systems, Inc. All rights reserved.
Room Control Using Touch10
Introduction to Video Conferencing
Your video system may have the
optional ability to control certain
room settings, like temperature,
blinds, curtains and light directly
from the Touch 10 control.
These optional settings are either
always available or context sensitive
(appearing only in a call or only
outside a call).
Exactly which settings that are avail-
able depends on the conguration
created by your video support team.
The screen-shot shown at left is just
one example of how it could be.
About Room Control
Use this icon to access global in-room settings, which
need to be accessible at all times. This typically includes
light, curtains, temperature etc. The icon itself may look
dierent, but the location of the icon is always as shown,
when applicable.
In addition you may have settings appearing only
when in a call or only when outside a call. At any rate,
the access icon for this will always be located here,
when applicable.

Cisco TelePresence MX200 G2 Specifications

General

Resolution	1920 x 1080
Network	10/100/1000 Ethernet
Product Type	Video conferencing system
Display Size	42 in
Camera	PrecisionHD 1080p Camera
Codec	Cisco TelePresence Codec
Video Inputs	HDMI, DVI-I
Video Outputs	HDMI
Control	Cisco Touch 10
Video Standards	H.264
Connectivity	HDMI
Codec Support	H.264
Resolution (fps)	1080p30
