Cisco UCS B200 M3 Blade Server
CONFIGURING the SERVER
19
Supported Configurations
(1) 1-Drive System
■ Select one of the drives listed in Table 8.
(1) 2-Drive System
■ Select two identical drives from Table 8. There is no support for mixing of drive types or
capacities.
Caveats
■ If you select two drives, they must be identical in type and capacity.
NOTE: The integrated RAID controller supports hard disk drives (HDDs) or solid state
drives (SSDs). Write cache is not implemented. SSDs are recommended for
applications requiring high-speed local storage, which is an order of magnitude
faster than HDDs.

Cisco UCS B200 M3 Specifications

General

System bus rate	8 GT/s
Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Motherboard chipset	Intel C600
Compatible processor series	Intel® Xeon®
Number of processors supported	2
ECC	Yes
Memory form factor	240-pin DIMM
Number of DIMM slots	24
Supported memory types	DDR3-SDRAM
Maximum internal memory	768 GB
RAID levels	0, 1
Storage drive sizes supported	2.5 \
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA III
USB 2.0 ports quantity	0
On-board graphics card model	Matrox G200
Chassis type	-
Product color	Silver
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 93 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	620 mm
Width	203 mm
Height	50 mm
Weight	4360 g
