Cisco UCS B200 M3 Blade Server
46
SUPPLEMENTAL MATERIAL
Adding an Additional CPU (with CPU heat sink)
All Cisco UCS two CPU socket-capable servers can be upgraded from having one to having two CPUs
configured. You will need to order and install a heat sink when adding any additional CPU to a server.
Instructions for installing the new CPU and heat sink can be found at the following link:
http://www.cisco.com/en/US/docs/unified_computing/ucs/hw/chassis/install/B200M3.html#wp1070500
Motherboard Lithium Battery
You can order a replacement motherboard battery. Installation instructions are found at this link:
http://www.cisco.com/en/US/docs/unified_computing/ucs/hw/chassis/install/B200M3.html#wp1034829
CPU Removal and Installation (“pick n place”) Tool Set
The Pick n Place tool set is used to install a CPU in its socket without damage. It must be used each time a
CPU is installed in a UCS “M3” server.
Instructions for using this tool set are found at the following link:
http://www.cisco.com/en/US/docs/unified_computing/ucs/hw/chassis/install/B200M3.html#wp1070500
Thermal Grease (with syringe applicator) for CPU to Heatsink Seal
Thermal grease must be applied to the top of the CPU where it comes in contact with the heat sink.
Instructions for applying thermal grease are found at:
http://www.cisco.com/en/US/docs/unified_computing/ucs/hw/chassis/install/B200M3.html#wp1070500
NOTE: When you purchase a spare CPU, the Pick n Place Toolkit is included.
CAUTION: Use only the thermal grease specified for this server
(UCS-CPU-GREASE=). This thermal grease comes in a blue-tipped syringe
and is to be used in all servers except the C220 M3 and C240 M3 servers,
which use thermal grease in a red-tipped syringe (UCS-CPU-GREASE2=).
Thermal grease in the red-tipped syringe is only to be used for the C220
M3 and C240 M3 servers and has different thermal conductivity
properties, which may cause overheating if used in the B200 M3 server.
Likewise, thermal grease in the blue-tipped syringe is only to be used for
all UCS servers other than the C220 M3 and C240 M3 (such as the B200 M3
server) and has different thermal conductivity properties, which may
cause overheating if used in the C220 M3 and C240 M3 servers.
DO NOT use thermal grease available for purchase at any commercial
electronics store. If these instructions are not followed, the CPU may
overheat and be destroyed.

Cisco UCS B200 M3 Specifications

General

System bus rate	8 GT/s
Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Motherboard chipset	Intel C600
Compatible processor series	Intel® Xeon®
Number of processors supported	2
ECC	Yes
Memory form factor	240-pin DIMM
Number of DIMM slots	24
Supported memory types	DDR3-SDRAM
Maximum internal memory	768 GB
RAID levels	0, 1
Storage drive sizes supported	2.5 \
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA III
USB 2.0 ports quantity	0
On-board graphics card model	Matrox G200
Chassis type	-
Product color	Silver
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 93 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	620 mm
Width	203 mm
Height	50 mm
Weight	4360 g
