Cisco UCS B200 M3 Blade Server
8
CONFIGURING the SERVER
STEP 1 VERIFY SERVER SKU
Verify the product ID (PID) of the server as shown in Table 2.
The base Cisco UCS B200 M3 blade server does not include the following components. They must
be selected during product ordering:
■ CPUs
■ Memory
■ Disk drives
■ Cisco adapters (such as the VIC 1240, VIC 1280, and Port Expander for VIC 1240)
■ Emulex and QLogic network adapters
■ Cisco UCS Storage Accelerators (such as the Fusion-io and LSI Logic adapter)
Table 2 PID of the Base UCS B200 M3 Blade Server
Product ID (PID) Description
UCSB-B200-M3 UCS B200 M3 Blade Server w/o CPU, memory, HDD, VIC 1240 adapter, or
mezzanine adapters
NOTE: Use the steps on the following pages to order servers with the
configurable components that you want configured in your servers.

Cisco UCS B200 M3 Specifications

General

System bus rate	8 GT/s
Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Motherboard chipset	Intel C600
Compatible processor series	Intel® Xeon®
Number of processors supported	2
ECC	Yes
Memory form factor	240-pin DIMM
Number of DIMM slots	24
Supported memory types	DDR3-SDRAM
Maximum internal memory	768 GB
RAID levels	0, 1
Storage drive sizes supported	2.5 \
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA III
USB 2.0 ports quantity	0
On-board graphics card model	Matrox G200
Chassis type	-
Product color	Silver
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 93 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	620 mm
Width	203 mm
Height	50 mm
Weight	4360 g
