Cisco UCS B200 M3 Blade Server
CONFIGURING the SERVER
9
STEP 2 CHOOSE CPU(S)
The standard CPU features are:
■ Intel Xeon E5-2600 v2 and E5-2600 series processor family CPUs. See the following link for
instructions on how to upgrade your server from Intel Xeon E5-2600 to Intel Xeon E5-2600 v2
CPUs as well as how to upgrade to 1866-MHz DIMMs (supported on E5-2600 v2 CPUs):
http://www.cisco.com/en/US/docs/unified_computing/ucs/hw/CPU/IVB/install/IVB-B.html
■ Intel C600 series chipset
■ Cache size of up to 30 MB for E5-2600 v2 CPUs or 20 MB for E5-2600 CPUs
Select CPUs
The available CPUs are listed in Table 3.
Table 3 Supported Intel CPUs: E5-2600 v2 and E5-2600 Series Processor Family CPUs
Product ID (PID)
Intel
Number
Clock
Freq
(GHz)
Power
(W)
Cache Size
(MB)
Cores QPI
Highest DDR3
DIMM Clock
Support (MHz)
1
Intel Xeon E5-2600 v2
UCS-CPU-E52697B E5-2697 v2 2.70 130W 30 12 8 GT/s 1866
UCS-CPU-E52695B E5-2695 v2 2.40 115 30 12 8 GT/s 1866
UCS-CPU-E52690B E5-2690 v2 3.00 130 25 10 8 GT/s 1866
UCS-CPU-E52680B E5-2680 v2 2.80 115 25 10 8 GT/s 1866
UCS-CPU-E52670B E5-2670 v2 2.50 115 25 10 8 GT/s 1866
UCS-CPU-E52667B E5-2667 v2 3.30 130 25 8 8 GT/s 1866
UCS-CPU-E52660B E5-2660 v2 2.20 95 25 10 8 GT/s 1866
UCS-CPU-E52658B E5-2658 v2 2.40 95 25 10 8 GT/s 1866
UCS-CPU-E52650B E5-2650 v2 2.60 95 20 8 8 GT/s 1866
UCS-CPU-E52640B E5-2640 v2 2.00 95 20 8 7.2 GT/s 1600
UCS-CPU-E52637B E5-2637 v2 3.50 130 15 4 8 GT/s 1866
UCS-CPU-E52630B E5-2630 v2 2.60 80 15 6 7.2 GT/s 1600
UCS-CPU-E52620B E5-2620 v2 2.10 80 15 6 7.2 GT/s 1600
UCS-CPU-E52643B E5-2643 v2 3.50 130 25 6 8 GT/s 1866
UCS-CPU-E52650LB E5-2650L v2 1.70 70 25 10 8 GT/s 1600
UCS-CPU-E52630LB E5-2630L v2 2.40 60 15 6 7.2 GT/s 1600
UCS-CPU-E52609B E5-2609 v2 2.50 80 10 4 6.4 GT/s 1333

Cisco UCS B200 M3 Specifications

General

System bus rate	8 GT/s
Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Motherboard chipset	Intel C600
Compatible processor series	Intel® Xeon®
Number of processors supported	2
ECC	Yes
Memory form factor	240-pin DIMM
Number of DIMM slots	24
Supported memory types	DDR3-SDRAM
Maximum internal memory	768 GB
RAID levels	0, 1
Storage drive sizes supported	2.5 \
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA III
USB 2.0 ports quantity	0
On-board graphics card model	Matrox G200
Chassis type	-
Product color	Silver
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 93 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	620 mm
Width	203 mm
Height	50 mm
Weight	4360 g
