Cisco UCS B200 M3 Blade Server
10
CONFIGURING the SERVER
Supported Configurations
(1) One-CPU Configuration
■ Choose one CPU from any one of the rows of Table 3 on page 9.
(2) Two-CPU Configuration
■ Choose two identical CPUs from any one of the rows of Table 3 on page 9.
Caveats
■ The B200 M3 configured with 1 CPU provides limited network connectivity options. The
following restrictions apply:
— A virtual interface card (VIC), the VIC 1240, must always be installed in the VIC 1240
mezzanine connector.
Intel Xeon E5-2600
2
UCS-CPU-E5-2690 E5-2690 2.90 135 20 8 8 GT/s 1600
UCS-CPU-E5-2680 E5-2680 2.70 130 20 8 8 GT/s 1600
UCS-CPU-E5-2670 E5-2670 2.60 115 20 8 8 GT/s 1600
UCS-CPU-E5-2667 E5-2667 2.90 130 15 6 8 GT/s 1600
UCS-CPU-E5-2665 E5-2665 2.40 115 20 8 8 GT/s 1600
UCS-CPU-E5-2660 E5-2660 2.20 95 20 8 8 GT/s 1600
UCS-CPU-E5-2658 E5-2658 2.10 95 20 8 8 GT/s 1600
UCS-CPU-E5-2650 E5-2650 2.00 95 20 8 8 GT/s 1600
UCS-CPU-E5-2650L E5-2650L 1.80 70 20 8 8 GT/s 1600
UCS-CPU-E5-2640 E5-2640 2.50 95 15 6 7.2 GT/s 1333
UCS-CPU-E5-2637 E5-2637 3.00 80 5 2 8 GT/s 1600
UCS-CPU-E5-2630 E5-2630 2.30 95 15 6 7.2 GT/s 1333
UCS-CPU-E5-2630L E5-2630L 2.00 60 15 6 7.2 GT/s 1333
UCS-CPU-E5-2620 E5-2620 2.00 95 15 6 7.2 GT/s 1333
UCS-CPU-E5-2643 E5-2643 3.30 130 10 4 8 GT/s 1600
UCS-CPU-E5-2609 E5-2609 2.40 80 10 4 6.4 GT/s 1066
Notes...
1. If higher or lower speed DIMMs are selected than what is shown in the table for a given CPU, the DIMMs will be
clocked at the lowest common denominator of CPU clock and DIMM clock.
2. 1866-MHz DIMMs are supported only with Intel Xeon E5-2600 v2 CPUs
Table 3 Supported Intel CPUs: E5-2600 v2 and E5-2600 Series Processor Family CPUs (continued)
Product ID (PID)
Intel
Number
Clock
Freq
(GHz)
Power
(W)
Cache Size
(MB)
Cores QPI
Highest DDR3
DIMM Clock
Support (MHz)
1

Cisco UCS B200 M3 Specifications

General

System bus rate	8 GT/s
Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Motherboard chipset	Intel C600
Compatible processor series	Intel® Xeon®
Number of processors supported	2
ECC	Yes
Memory form factor	240-pin DIMM
Number of DIMM slots	24
Supported memory types	DDR3-SDRAM
Maximum internal memory	768 GB
RAID levels	0, 1
Storage drive sizes supported	2.5 \
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA III
USB 2.0 ports quantity	0
On-board graphics card model	Matrox G200
Chassis type	-
Product color	Silver
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 93 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	620 mm
Width	203 mm
Height	50 mm
Weight	4360 g
