Cisco UCS B200 M3 User Manual

Cisco UCS B200 M3 Blade Server
TECHNICAL SPECIFICATIONS
63
TECHNICAL SPECIFICATIONS
Dimensions and Weight
Power Specifications
For configuration-specific power specifications, use the Cisco UCS Power Calculator at:
https://express.salire.com/Go/Cisco/Cisco-UCS-Power-Calculator.aspx
Table 31 UCS B200 M3 Dimensions and Weight
Parameter Value
Height 1.95 in. (50 mm)
Width 8.00 in.(203 mm)
Depth 24.4 in. (620 mm)
Weight ■ Base server weight
(no CPUs, no HDDs, no mezzanine adapters or memory) = 9.62 lbs (4.36 kg)
■ Minimally configured server
(1 HDD, 2 CPUs, a VIC 1240 but no mezzanine adapter) = 12.50 lbs (5.67 kg)
■ Fully configured server
(2 HDDs, 2 CPUs, all memory, VIC 1240 and mezzanine adapter both populated) = 14.98
lbs (6.79 kg)

Cisco UCS B200 M3 Specifications

General

System bus rate	8 GT/s
Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Motherboard chipset	Intel C600
Compatible processor series	Intel® Xeon®
Number of processors supported	2
ECC	Yes
Memory form factor	240-pin DIMM
Number of DIMM slots	24
Supported memory types	DDR3-SDRAM
Maximum internal memory	768 GB
RAID levels	0, 1
Storage drive sizes supported	2.5 \
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA III
USB 2.0 ports quantity	0
On-board graphics card model	Matrox G200
Chassis type	-
Product color	Silver
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 93 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	620 mm
Width	203 mm
Height	50 mm
Weight	4360 g
