Cisco UCS B200 M3 Blade Server
SUPPLEMENTAL MATERIAL
47
Air Baffle Replacement Kit
Air baffles are designed to direct airflow through the server to maintain server temperature at a safe
operating level. The UCS B200 M3 server comes shipped with two identical air baffles covering the DIMM
socket areas of the server. These baffles must always remain installed during server operation. The Air
Baffle Replacement Kit includes the two (identical) air baffles needed for one UCS B200 M3 server. For
instructions on how to remove and replace the air baffles, see the following link:
http://www.cisco.com/en/US/docs/unified_computing/ucs/hw/chassis/install/B200M3.html#wp1034378
CPU Heat Sink Cleaning Kit
The cleaning kit is used to remove the existing thermal compound from the bottom of the heat sink during
a CPU replacement process. Instructions for cleaning are found at the following link:
http://www.cisco.com/en/US/docs/unified_computing/ucs/hw/chassis/install/B200M3.html#wp1010281
NOTE: When you purchase a spare CPU, the thermal grease with syringe applicator
is included.
NOTE: When you purchase a spare CPU, the CPU cleaning kit is included.

Cisco UCS B200 M3 Specifications

General

System bus rate	8 GT/s
Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Motherboard chipset	Intel C600
Compatible processor series	Intel® Xeon®
Number of processors supported	2
ECC	Yes
Memory form factor	240-pin DIMM
Number of DIMM slots	24
Supported memory types	DDR3-SDRAM
Maximum internal memory	768 GB
RAID levels	0, 1
Storage drive sizes supported	2.5 \
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA III
USB 2.0 ports quantity	0
On-board graphics card model	Matrox G200
Chassis type	-
Product color	Silver
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 93 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	620 mm
Width	203 mm
Height	50 mm
Weight	4360 g
