Cisco UCS B200 M3 User Manual

Cisco UCS B200 M3 Blade Server
CONFIGURING the SERVER
21
Supported Configurations
(1) B200 M3 configured with 1 CPU
For a B200 M3 configured with 1 CPU, the supported configurations are listed in Table 10.
Choose one configuration.
Converged Network Adapters (CNAs)
UCSB-MEZ-QLG-03 Cisco UCS CNA M73KR-Q QLogic Adapter Mezzanine
UCSB-MEZ-ELX-03 Cisco UCS CNA M73KR-E Emulex Adapter Mezzanine
Cisco Storage Accelerators
UCSB-F-FIO-785M Cisco UCS 785 GB MLC Fusion-io ioDrive2 Mezzanine
UCSB-F-FIO-365M Cisco UCS 365 GB MLC Fusion-io ioDrive2 Mezzanine
UCSB-F-LSI-400S LSI 400 GB SLC WarpDrive Mezzanine
Expander Option
UCSB-MLOM-PT-01 Cisco UCS Port Expander Card for VIC 1240. This is a hardware
option to enable an additional 4 ports of the VIC 1240, bringing
the total capability of the VIC 1240 to dual 4 x 10 GbE
Mezzanine
Table 10 Supported VIC 1240 and Mezzanine Adapter Configurations
Fabric
Extender
Compatibility
Adapter in
VIC 1240 Slot
Adapter in Mezzanine Slot Ports Reference
2208XP (PIDs UCS-IOM-2208XP, UCS-IOM2208-16FET)
2208XP VIC 1240 None 4 x 10 Gb Figure 10 on page 52
2208XP VIC 1240 Port Expander Card for VIC 1240 8 x 10 Gb Figure 11 on page 53
2204XP (PIDs UCS-IOM-2204XP, UCS-IOM2204-8FET)
2204XP VIC 1240 None 2 x 10 Gb Figure 12 on page 54
2204XP VIC 1240 Port Expander Card for VIC 1240 4 x 10 Gb Figure 13 on page 54
2104XP (PID N20-I6584)
2104XP VIC 1240 None 2 x 10 Gb Figure 14 on page 55
Table 9 Supported Mezzanine Adapters (continued)
Product ID (PID) PID Description Connector

Cisco UCS B200 M3 Specifications

General

System bus rate	8 GT/s
Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Motherboard chipset	Intel C600
Compatible processor series	Intel® Xeon®
Number of processors supported	2
ECC	Yes
Memory form factor	240-pin DIMM
Number of DIMM slots	24
Supported memory types	DDR3-SDRAM
Maximum internal memory	768 GB
RAID levels	0, 1
Storage drive sizes supported	2.5 \
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA III
USB 2.0 ports quantity	0
On-board graphics card model	Matrox G200
Chassis type	-
Product color	Silver
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 93 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	620 mm
Width	203 mm
Height	50 mm
Weight	4360 g
