Cisco UCS C24 M3 High-Density SFF Rack-Mount Server
54
SUPPLEMENTAL MATERIAL
See Table 27 for the functions of the rear panel LEDs.
Table 27 Rear Panel LEDs
LED LED State Meaning
Power Supply Fault Off The power supply is operating normally
Blinking (amber) An event warning threshold has been reached, but the
power supply continues to operate
On (amber) A critical fault threshold has been reached, causing the
power supply to shut down (for example, a fan failure or
an over-temperature condition).
Power Supply AC Off There is no AC power to the power supply
Blinking (green) AC power OK, DC output not enabled
On (green) AC power OK, DC outputs OK
1 GbE Link Speed Off Link Speed = 10 MbpS
On (amber) Link Speed = 100 MbpS
On (green) Link Speed = 1 GbpS
1 GbE Link Status Off No Link
On (green) Link is active
Blinking (green) Traffic is present on the active link
10/100/1000 Base-T
Link Speed
Off Link Speed = 10 Mbps
On (amber) Link Speed = 100 Mbps
On (green) Link Speed = 1 Gbps
10/100/1000 Base-T
Link Status
Off No Link
On (green) Link is active
Blinking (green) Traffic is present on the active link
Unit ID
(LED is integrated into
unit ID button)
Off Unit ID not active
On (blue) Unit ID is activated
