Configuring Stub Routing
To disable PIM stub routing on an interface, use the no ip pim passive interface configuration command.
In this example, IP multicast routing is enabled, Switch A PIM uplink port 25 is configured as a routed
uplink port with spare-dense-mode enabled. PIM stub routing is enabled on the VLAN 100 interfaces
and on Gigabit Ethernet port 20 in Figure 34-4:
Switch(config)# ip multicast-routing distributed
Switch(config)# interface GigabitEthernet0/25
Switch(config-if)# no switchport
Switch(config-if)# ip address 3.1.1.2 255.255.255.0
Switch(config-if)# ip pim sparse-dense-mode
Switch(config-if)# exit
Switch(config)# interface vlan100
Switch(config-if)# ip pim passive
Switch(config-if)# exit
Switch(config)# interface GigabitEthernet0/20
Switch(config-if)# ip pim passive
Switch(config-if)# exit
Switch(config)# interface vlan100
Switch(config-if)# ip address 100.1.1.1 255.255.255.0
Switch(config-if)# ip pim passive
Switch(config-if)# exit
Switch(config)# interface GigabitEthernet0/20
Switch(config-if)# no switchport
Switch(config-if)# ip address 10.1.1.1 255.255.255.0
Switch(config-if)# ip pim passive
Switch(config-if)# end
To verify that PIM stub is enabled for each interface, use the show ip pim interface privileged EXEC
command:
Switch#show ip pim interface
Address Interface Ver/ Nbr Query DR DR
Mode Count Intvl Prior
3.1.1.2 GigabitEthernet0/25 v2/SD 1 30 1 3.1.1.2
100.1.1.1 Vlan100 v2/P 0 30 1 100.1.1.1
10.1.1.1 GigabitEthernet0/20 v2/P 0 30 1 10.1.1.1
Use these privileged EXEC commands to display information about PIM stub configuration and status:
• show ip pim interface displays the PIM stub that is enabled on each interface.
• show ip igmp detail displays the interested clients that have joined the specific multicast source
group.
• show ip igmp mroute verifies that the multicast stream forwards from the source to the interested
clients.
Step 4
end Return to privileged EXEC mode.
Step 5
show ip pim interface Display the PIM stub that is enabled on each interface.
Step 6
show running-config Verify your entries.
Step 7
copy running-config startup-config (Optional) Save your entries in the configuration file.
