Chapter 38 Configuring HSRP and Enhanced Object Tracking
Configuring HSRP
Figure 38-2 MHSRP Load Sharing
Configuring HSRP
These sections contain this configuration information:
• Default HSRP Configuration, page 38-5
• HSRP Configuration Guidelines, page 38-5
• Enabling HSRP, page 38-5
• Configuring HSRP Priority, page 38-6
• Configuring MHSRP, page 38-9
• Configuring HSRP Authentication and Timers, page 38-9
• Enabling HSRP Support for ICMP Redirect Messages, page 38-11
121235
Active router for group 1
Standby router for group 2
Client 1
Router A Router B
10.0.0.1 10.0.0.2
Active router for group 2
Standby router for group 1
Client 2 Client 3 Client 4
