Cisco WS-C3020 - Configuring LLDP-MED Tlvs

25-6
Cisco Catalyst Blade Switch 3020 for HP Software Configuration Guide
OL-8915-03
Chapter 25 Configuring LLDP and LLDP-MED
Configuring LLDP and LLDP-MED
Beginning in privileged EXEC mode, follow these steps to enable LLDP on an interface when it has been
disabled:
This example shows how to enable LLDP on an interface.
Switch# configure terminal
Switch(config)# interface GigabitEthernet0/1
Switch(config-if)# lldp transmit
Switch(config-if)# lldp receive
Switch(config-if)# end
Configuring LLDP-MED TLVs
By default, the switch only sends LLDP packets until it receives LLDP-MED packets from the end
device. It will then send LLDP packets with MED TLVs as well. When the LLDP-MED entry has been
aged out, it only sends LLDP packets again.
Using the lldp interface command, you can configure the interface not to send the following TLVs:
Beginning in privileged EXEC mode, follow these steps to disable a TLV on an interface:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the interface on which you are enabling LLDP-MED, and
enter interface configuration mode.
Step 3
lldp transmit LLDP packets are sent on the interface.
Step 4
lldp receive LLDP packets are received on the interface.
Step 5
end Return to privileged EXEC mode.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
Table 25-2 LLDP-MED TLVs
LLDP-MED TLV Description
inventory-management LLDP-MED inventory management TLV
location LLDP-MED location TLV
network-policy LLDP-MED network policy TLV
power-management LLDP-MED power management TLV
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the interface on which you are configuring a LLDP-MED
TLV, and enter interface configuration mode.
Step 3
no lldp med-tlv-select tlv Specify the TLV to disable.
Step 4
end Return to privileged EXEC mode.
Step 5
copy running-config startup-config (Optional) Save your entries in the configuration file.
