Cisco WS-C3020 - Using FTP to Access the MIB Files

To Next Page

To Previous Page

A-3

Cisco Catalyst Blade Switch 3020 for HP Software Configuration Guide

OL-8915-03

Appendix A Supported MIBs

Using FTP to Access the MIB Files

• SNMP-FRAMEWORK-MIB

• SNMP-MPD-MIB

• SNMP-NOTIFICATION-MIB

• SNMP-TARGET-MIB

• SNMPv2-MIB

• TCP-MIB

• UDP-MIB

Note You can access other information about MIBs and Cisco products on the Cisco web site:

http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml

Using FTP to Access the MIB Files

You can get each MIB file by using this procedure:

Step 1 Make sure that your FTP client is in passive mode.

Note Some FTP clients do not support passive mode.

Step 2 Use FTP to access the server ftp.cisco.com.

Step 3 Log in with the username anonymous.

Step 4 Enter your e-mail username when prompted for the password.

Step 5 At the ftp> prompt, change directories to /pub/mibs/v1 and /pub/mibs/v2.

Step 6 Use the get MIB_filename command to obtain a copy of the MIB file.
