CITIZEN Android Label Print SDK — Programming Manual
75
2.3.12 drawAztec method
Syntax
int drawAztec (String data, int encoding, int rotation, int exp, int ECLevel, int x, int y)
Parameters
Parameter
[IN/OUT]
Description
Setting range
data
[IN]
String data
* The characters available with the specified
encoding.
encoding
[IN]
Character encoding
See #9 in "3.3.Predefined Constants."
rotation
[IN]
Direction of rotation
CLS_RT_NORMAL: No rotation
CLS_RT_RIGHT90: Rotate CW 90
CLS_RT_ROTATE180: Rotate CW 180
CLS_RT_LEFT90: Rotate CCW 90
exp
[IN]
Magnification
1-15
ECLevel
[IN]
Error correction level
CLS_AXTEC_EC_LEVEL_000:
Level 0 (Error correction ratio 23%)
x
[IN]
X-coordinate
0000-9999
* The origin is at bottom-left.(0, 0)
y
[IN]
Y-coordinate
Description
Draws the Aztec barcode with specifying options such as character encoding, rotation, magnification,
EC level and coordinates.
Return value
Returns CLS_SUCCESS(0) on success, an error code otherwise. See "2.1 Return value" for the error
codes.
Example
design.drawAztec("0123456789",
LabelConst.CLS_ENC_CDPG_US_ASCII,
LabelConst.CLS_RT_NORMAL, 10,
LabelConst.CLS_AXTEC_EC_LEVEL_000, 0, 0);

Citizen CL-S521 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 DPI
PC connected	Yes
Standard interfaces	USB 1.1, Serial
Optional connectivity	Ethernet, Serial (RS-232)
USB 1.1 ports quantity	1
Connectivity technology	Wired
Flash memory	4 MB
Internal memory	16 MB
Compatible operating systems	Windows 7/XP/2003/2008/Vista
Form factor	Desktop
Core diameter	25 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	1625.6 mm
Maximum roll diameter	125 mm
Supported paper width	12.5 - 118.1 mm
Media thickness (imperial)	0.0025 - 0.01 \
Supported paper width (imperial)	0.50 - 4.65 \
Product color	Gray
Housing material	Metal, Plastic

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	183 mm
Weight	3600 g
