Citizen CLP-7202e - System Maintenance Mode

Chapter 2 Printer Operation 

32
5 System Maintenance Mode
In system maintenance mode, the communication, adjustable sensor ON/OFF and sensor
voltage selections are set up. The printer configuration settings are stored in memory so
they are maintained even after the power is turned off. Control key functions are shown in
the following:
Example: Setting the black mark sensor voltage
1. First turn OFF the power switch, then press and hold the PAUSE, FEED and STOP keys
simultaneously and at the same time turn ON the power switch.
2. Change the baud rate to the sensor voltage setting with the PAUSE key pressed.
On Line
Pressing all these keys
simultaneously places the printer
into system maintenance mode.
Return to normal
operating mode.
Selects the mode item.
Selects the mode.
9600bps
9600bps
PE.*.**V
5 System Maintenance Mode
