Appendixes
68
2 Specifications
Main Specifications
Item CLP-7201e/7202e
Main scanning line density: 203 dots/in (8 dots/mm) Resolution
Sub-scanning line density: 203 dots/in (8 dots/mm)
Printing method Direct-thermal or thermal-transfer printing
Max. print width 104 mm
4.1 in
Max. print length 812.8 mm 32 in
Printing
Print density Adjustable with software
Printing
speed
Printing speed setting 2
−
7 in/sec in one-inch units
Batch mode Performs normal printing (single or multiple sheets)
Peel mode Peels labels from the liners after printing labels
Cut mode
Prints and cuts by the specified number of sheets (label
back-feeding enabled)
Print mode
Tear-off mode
Feeds back media to the print starting position after tearing
media
Types of media Roll or fanfold media (continuous labels, die-cuts,
continuous tags or tickets)
Kinds of media Direct-thermal or thermal-transfer media
Max. liner width 118 mm 4.65 in
Min. liner width 25.4 mm 1 in
Min. label width 7.62 mm 0.3 in
Min. media pitch
5.08 mm 0.2 in
Max. media thickness 0.254 mm 0.01 in
Min. media thickness 0.0635 mm 0.0025 in
Media
On-board roll media
diam.
Max. outer diam.: 203 mm
Media core: 38−76 mm
8 in
1.5−3 in
Width 25.4−114 mm (1−4.5 in) freely adjustable
Length, max. 360 m 1,181 ft
Max. outer diam. 74 mm 2.91 in
Ribbon
Media core inner diam. 25.4 mm
±0.254 mm
1 in
±0.01 in
2 Specifications
