Chapter 3 Media and Ribbon
45
5. Wind the ribbon being pulled out around the ribbon holder and fix it to the core with
adhesive tape. Set the ribbon holder on the transfer mechanism. Then turn its knob in the
direction of arrow to remove the slack or wrinkle of the ribbon. Also any slack or wrinkle of
the ribbon must be removed from the bottom of the transfer mechanism.
6. Push down the green part of the push button to close the printer mechanism until it clicks.
7. Close the printer cover.
8. Turn ON the power switch of the printer. The LCD screen on the control panel will show
‘On Line.’ Then press the FEED key and media will advance to the next label position and
stop.
6 Ribbon Settin
Make sure the green part of the push button is pressed properly. Otherwise, the printer
mechanism may fail to close.
CAUTION
