Appendixes
71
Interfaces
The printer is connected to a computer and prints labels according to the command from the
computer. Two systems of interface connection to a computer are shown below.
1. Serial interface: RS-232C
System Asynchronous serial interface
RS-232C
Connector DSUB 25-pin
Handshaking XON/XOFF and CTS/DTR
Receive buffer
size
32K bytes
Receiving data stops when the receive buffer reaches 2K bytes
and resumes receiving data when the receive buffer reaches
4K bytes
Baud rate 300, 600, 1200, 2400, 4800, 9600, 19200, 38400 bps
Bit length 7- or 8-bit
Stop bit Fixed
When printer is receiving data, stop bit is fixed at 1, and when
printer is transmitting data, stop bit is fixed at 2. But computer
can transmit or receive data, regardless of stop bit at 1 or 2
Parity No
2. Parallel interface: IEEE1284 compatible and nibble modes
System 8-bit parallel
Connector 36-pin unphenol type
Synchronous syst
em
Strobe pulse
Handshaking ACKNLG and BUSY signals
Signal level TTL
2 Specifications
