Citrix ADC MPX User Manual

Citrix ADC MPX
The T1300 appliance has the following ports:
• Two 10/100/1000BASE‑T, RJ45 management plane ports
• One 10/100BASE‑T, RJ‑45 LOM port
• 32 10GBASE‑X SFP+ data plane ports (T1300‑10GE)
• Four 40G QSFP+ data plane ports (T1300‑40GE)
• 16 10GBASE‑X SFP+ data plane ports (T1300‑40GE)
The following figure shows the back panel of the T1300 appliance.
Figure 2. Citrix ADC T1300 back panel
The following components are visible on the back panel of the T1300 appliance:
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 104

Citrix ADC MPX Specifications

General

Category	Network Hardware
Type	Application Delivery Controller
Virtualization Support	Yes
Power Supply	Redundant power supplies
High Availability	Yes
Product Series	Citrix ADC
Model	MPX
Ports	Varies by model
Redundancy	Yes
Protocols Supported	HTTP, HTTPS, TCP, SSL, DNS
Security Features	DDoS protection
Operating System	Citrix ADC
