12. On appliance B, enable appliance B as the target appliance. At the command prompt, type:
1 enable ssl fipsSIMtarget <keyVector> <sourceSecret>
2 <!--NeedCopy-->
Example:
enable fipsSIMtarget /nsconfig/ssl/nodeB.key /nsconfig/ssl/nodeA.secret
13. Export the FIPS keys on appliance A.
Example:
export fipskey Key-FIPS-1 -key Key-FIPS-1.key
14. Copy the key file to appliance B, in the /nconfig/ssl folder.
Example:
scp /nsconfig/ssl/nodeA.key nsroot@198.51.100.10:/nsconfig/ssl
15. Import the FIPS keys on appliance B.
Example:
import fipskey Key-FIPS-2 -key Key-FIPS-2.key -inform SIM -exponent F4
16. Copy the certificate files to appliance B, in the /nconfig/ssl folder.
Example:
scp /nsconfig/ssl/nodeA.cert nsroot@198.51.100.10:/nsconfig/ssl
17. Copy the rest of the configuration from appliance A to appliance B.
Troubleshooting
September 19, 2022
I cannot access the Citrix ADC appliance aer it is restarted. The Citrix ADC IP address
(NSIP) is not accessible and does not respond to a ping request
Citrix ADC MPX 8005/8015/8200/8400/8600/8800, MPX 11500/13500/14500/16500/18500/20500, MPX
11515/11520/11530/11540/11542, MPX17550/19550/20550/21550, MPX 22040/22060/22080/22100/22120,
MPX 24100/24150, MPX 25100T/25160T, T1010, T1100, T1200, T1300, and T1310 appliances support
LOM. Depending on the state of the LOM configuration, start with one of the steps in the following
procedure. To configure the LOM port, see Lights out management port of the Citrix ADC appliance.
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 217

Citrix ADC MPX Specifications

General

Category	Network Hardware
Type	Application Delivery Controller
Virtualization Support	Yes
Power Supply	Redundant power supplies
High Availability	Yes
Product Series	Citrix ADC
Model	MPX
Ports	Varies by model
Redundancy	Yes
Protocols Supported	HTTP, HTTPS, TCP, SSL, DNS
Security Features	DDoS protection
Operating System	Citrix ADC
