Citrix ADC MPX User Manual

Citrix ADC MPX
Bezel
The bezel of a Citrix ADC appliance is now available as a FRU and can be replaced in the field.
Note
The bezel FRU is supported only on the MPX/SDX 9100 platform.
To replace the bezel
1. Remove the five screws that attach the bezel to the chassis front.
2. Disconnect the cable (see image).
3. Discard the old bezel.
4. Reconnect the cable to the new bezel.
5. Attach the new bezel to the chassis front using screws.
Figure 1: Replacing the 2U bezel
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 122

Citrix ADC MPX Specifications

General

Category	Network Hardware
Type	Application Delivery Controller
Virtualization Support	Yes
Power Supply	Redundant power supplies
High Availability	Yes
Product Series	Citrix ADC
Model	MPX
Ports	Varies by model
Redundancy	Yes
Protocols Supported	HTTP, HTTPS, TCP, SSL, DNS
Security Features	DDoS protection
Operating System	Citrix ADC
