Citrix ADC MPX
Short reach fiber 10G SFP+ distance specifications
Applicable platforms:
• MPX 8005/8015/8200/8400/8600/8800/8900
• MPX 9100
• MPX 22000
• MPX 24000
• MPX 25000T
• MPX 25100 40G, MPX 25160 40G
• MPX 14000
• MPX 14000‑40G
• MPX 14000‑40S
• MPX 14000 FIPS
• MPX 15000
• MPX 15000‑50G (adapter required to connect 50G ports to 10G transceiver)
• MPX 16000 (adapter required to connect 100G ports to 10G transceiver)
• MPX 26000 (adapter required to connect 50G ports to 10G transceiver)
• MPX 26000‑50S (adapter required to connect 50G ports to 10G transceiver)
• MPX 26000‑100G (adapter required to connect 100G ports to 10G transceiver)
Description
Transmitter
Wavelength (nm) Fiber Type Typical Reach (m)
Citrix ADC 10G SFP+,
Ethernet Short Range
(300 m) ‑ Single
850 nm (nominal) 50/125um MMF,
2000MHz‑ km (OM3)
300 m
50/125um MMF,
500MHz‑km (OM2)
82 m
50/125um MMF,
400MHz‑km
66 m
62.5/125um MMF,
200MHz‑km (OM1)
33 m
62.5/125um MMF,
160MHz‑km
26 m
Long reach fiber 10G SFP+ distance specifications
Description: Citrix ADC 10G SFP+ Ethernet long range (10 km) ‑ Single
Transmitter wavelength (nm): 1310 nm (nominal)
