Citrix ADC MPX User Manual

Citrix ADC MPX
Health
attribute Unit
Lower
Non‑
Recoverable
Lower
Critical
Lower
Non‑
Critical
Upper
Non‑
Critical
Upper
Critical
Upper
Non‑
Recoverable
PS_2
Temp
degrees C ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑
PS_3
Status
discrete ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑
PS_3 FAN RPM ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑
PS_3
Temp
degrees C ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑
PS_4
Status
discrete ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑
PS_4 FAN RPM ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑
PS_4
Temp
degrees C ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑
FPC
Status
discrete ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑
VTT Volts 0.816 0.864 0.912 1.344 1.392 1.440
CPU1
Vcore
Volts 0.480 0.512 0.544 1.488 1.520 1.552
CPU2
Vcore
Volts 0.480 0.512 0.544 1.488 1.520 1.552
VDIMM AB Volts 1.104 1.152 1.200 1.648 1.696 1.744
VDIMM
CD
Volts 1.104 1.152 1.200 1.648 1.696 1.744
VDIMM EF Volts 1.104 1.152 1.200 1.648 1.696 1.744
VDIMM
GH
Volts 1.104 1.152 1.200 1.648 1.696 1.744
+1.5 V Volts 1.248 1.296 1.344 1.648 1.696 1.744
3.3 V Volts 2.640 2.784 2.928 3.648 3.792 3.936
+3.3VSB Volts 2.640 2.784 2.928 3.648 3.792 3.936
5 V Volts 4.096 4.288 4.480 5.504 5.696 6.912
12 V Volts 10.176 10.494 10.812 13.250 13.568 13.886
