230
AXLES
SUSPENSION
STEERING
XSARA - All Types
Steering wheel - Manual steering
MANUAL STEERING SPECIFICATIONS
- (a) : L.H.D./R.H.D = White.
- (L) : Shaft length = 311 ± 1.5 mm.
- (1) Steering wheel fitted with AIRBAG.
(according to equipment).
- (4) Steering column adjustment lever.
Tightening torques (m.daN).
- (2) AIRBAG to steering wheel fixing : 0.8
- (3) Steering wheel fixing : 3.3
- (5) Steering column to support fixing : 2.3
- (6) Steering cardan joint fixing : 2.3
- (b) = Locating bush.
The locating bush must be centred in the reference window
before tightening the cardan bolts (6).
B3EP08PD
