245
AXLES
SUSPENSION
STEERING
STEERING COLUMN SPECIFICATIONS
Left hand drive = Green marking.
Right hand drive = White marking.
(1) Steering wheel.
(4) Steering column adjustment.
Tightening torques m.daN.
(2) Airbag to steering wheel fixing 0.8 ± 0.1
(3) Steering wheel fixing 3.3 ± 0.6
(5) Steering column to support fixing 4 ± 1
(6) Steering cardan joint fixing 2.3 ± 0.2
B3EP116D
XSARA PICASSO - All Types
